| voltage | DC12~24V |
| Detect magnetic poles | LSPSC0012-S: S pole |
| LSPSC0012-N: N pole |
| Magnetic sensitivity | 2.5~3.5mT |
| Magnetic detection direction | down |
| Output current | 50mAMAX |
| Leakage current | When OFF, maximum 0.5mA or less |
| Response time | 50m sec |
| Withstand voltage | AC1000V |
| 1 minute, between the entire charging part and the casing |
| Insulation resistance | DC250V |
| 20MΩ or more, between the entire charging part and the casing |
| Working temperature |
|
| Working environment humidity | 20~95%RH |
| Wire specifications | Φ3.2×1000mm※1 |
| S pole: gray |
| N pole: black |
| shell material | Glass fiber reinforced resin: gray |
| Install | Special installation accessories |
| indicator light | red |
| protection level | IP67 |
Note: Please be sure to connect the load before use
※1 The cable can be extended
