| voltage | DC5~24V |
| Detect magnetic poles | LSPSC02 □ S: S pole |
| LSPSC02 □ N: N pole |
| Magnetic sensitivity | 3~4mT |
| Magnetic detection direction | down |
| output method | NPN normally open (ON during operation) | ※1※2 |
| Output current | 20mA MAX ※1 |
| Current consumption | 8mAMAX |
| Response time | 16μ sec or less |
| Withstand voltage | AC1000V |
| 1 minute, between the entire charging part and the casing |
| Insulation resistance | DC250V |
| 20MΩ or more, between the entire charging part and the casing |
| Working temperature | - 20℃~ +85℃ (no condensation) |
| Working environment humidity | 20~95%RH |
| Wire specifications | φ2.6×1000mm※1 |
| S pole: gray |
| N pole: black |
| shell material | Glass fiber reinforced resin: black |
| Install | Comes with screw tightening torque 0.06N·m |
| indicator light | red |
| protection level | IP67 |
※1 Output conversion and current amplification can be achieved through wire accessories.
Cable extension, please refer to P.127 ~ 130 for details. ※2 Please refer to P58 for output PNP.
