| voltage | DC5 ~ 24V |
| journey | 1.5mm |
| Operating force | 0.4N Note) |
| Working point position [PT] | 0.2 ~ 0.5mm |
| Return difference[MD] | 0.1mm or less |
| Repeatability | ±0.001mm |
| output method | LSTSM8： |
| NPN normally open (ON during operation) |
| LSTSM8(B：) |
| NPN normally closed (OFF during action) |
| Output current | 15mA MAX |
| Current consumption | 8mA MAX |
| working frequency | 60 times/min or less |
| Withstand voltage | AC1000V |
| 1 minute, between the entire charging part and the casing |
| Insulation resistance | DC250V |
| 20MΩ or more, between the entire charging part and the casing |
| Working temperature |
|
| Working environment humidity | 20 ~ 95％ RH |
| Wire specifications | φ2.8×1000mm |
| LSTSM8: gray |
| LSTSM8(B:) black |
| Material | Shell/nut/operating rod: SUS303 |
| Install | M8 nut, tightening torque 5N·m or less |
| Installation hole diameter processing dimensions | φ8 ＋0(0).5 |
| indicator light | LSTSM8-LED | Approximately 100mm from the sensor body |
| LSTSM8(B)-LED |
| protection level | IP67 |
Note) Please do not apply more than 30N force to the operating lever.
