| voltage | DC5~24V |
| output method | Normally closed NC |
| journey | 4.5mm |
| Operating force | 2.5N |
| Working point position [PT] | 0.1~0.3mm |
| Return difference[MD] | 0.1mm or less |
| Repeatability | 0.01mm |
| Output current | 50mAMAX |
| Current consumption | OFF state, maximum 0.5mA or less |
| Response time | 50ms |
| Withstand voltage | AC1000V |
| 1 minute, between the entire charging part and the casing |
| Insulation resistance | DC250V |
| 20MΩ or more, between the entire charging part and the casing |
| Working temperature | -20℃~ +85℃(no condensation) |
| Working environment humidity | 20~95%RH |
| protection level | IP65 (except connection parts) |
Note) Please do not apply excessive pressure to the cable section
