LSMB
Technical Parameters
Outline drawing & circuit diagram
modelSingle unit specificationsDedicated power supply specifications
ZMB3()A24ZMB3()P24
Rated voltageDC24V±10%
Instantaneous maximum power
7.2W
Power consumption2.4W or lessBelow 1W
static friction moment20N.cm36N.cm
Pick-up time40msec or less
release time10msec or less
Pull-in voltageBelow 20V
Release voltageAbove 3V10V or more
moment of inertia3.2g.cm²
Insulation resistanceDC500V ≥10MΩ
Insulation withstand voltageAC1000V- 1 minute
Insulation class weightClass F
100g112g
Rotor inner diameterMedium 6, φ8 (H7)
