 voltage | DC5～24V |
| Magnetic detection direction | forward |
| Maximum detection distance | Iron 10×10×1t 3.5mm |
| output method | NPN normally open |
| LSPSF013: (ON during operation) ※ 1 |
| LSPSF013(B): (OFF during operation) |
| Output current | 15mAMAX1 |
| Current consumption | 8mAMAX |
| Withstand voltage | AC1000V |
| 1 minute, between the entire charging part and the casing |
| Insulation resistance | DC250V |
| 20MΩ or more, Between the entire charging part and the casing |
| Working temperature | - 20℃～ +85℃ (no condensation) |
| Working environment humidity | 20～80%RH |
| Wire specifications | φ2.8×1000mm ※1 |
| LSPSF013: gray |
| LSPSF013(B): black |
| shell material | SUS303 |
| Install | M14 nut, tightening torque 18N·m |
| Installation hole diameter processing dimensions | 0.50 |
| indicator light | red |
