Work performance
NPN current boost (no output switching)
Specification
| voltage | DC5 ~ 24V Note) |
| output method | NPN normally open (ON when approaching/moving) |
| Output current | 80mA MAX Note) |
| Output status | low level |
| indicator light | Red LED (lights up when ON) |
Note) 80mA only in the case of DC12~24V
